Santerno Sinus Penta - Page 238

SINUS PENTA
PROGRAMMING GUIDE
238/486
P353 MPL1: Testing Variable A
P353 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
953
Function
This parameter defines the test to be performed for the variable detected by
P351 using P355 as a comparing value.
P354 MPL1: Testing Variable B
P354 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
954
Function
This parameter defines the test to be performed for the variable detected by
P352 using P356 as a comparing value.
P355 MPL1: Comparing Value for Test A
P355 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see
Table
48
Default
0
0
Level
ADVANCED
Address
955
Function
This parameter defines the comparing value with the selected variable for test A.
P356 MPL1: Comparing Value for Test B
P356 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see
Table
48
Default
0
0
Level
ADVANCED
Address
956
Function
This parameter defines the comparing value with the selected variable for test B.
