P357 MPL1: Function Applied to the Result of the 2 Tests
P357 Range
0 ÷ 12
0: (A) OR (B)
1: (A) SET (B) RESET
2: (A) AND (B)
3: (A) XOR (B)
4: (A) NOR (B)
5: (A) NAND (B)
6: (A\) OR (B)
7: (A) OR (B\)
8: (A\) AND (B)
9: (A) AND (B\)
10: (A) RESET (B) SET RISING EDGE
11: (A) SET (B) RESET FALLING EDGE
12: (A) RESET (B) SET FALLING EDGE
Default
0
0: (A) OR (B)
Level
ADVANCED
Address
957
Function
This parameter determines the logic function applied to the result of the tests
allowing calculating the output value.
P357a MPL1: Selecting Variable C
P357a
Range
0 ÷ 79
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
932
Function
This parameter selects the digital signal used to calculate the value of MPL1
digital output.
The digital signals that can be selected are given in Table 48.
P357b MPL1: Function Applied to the Result of f(A,B) C
P357b Range
0 ÷ 12
0: f(A,B) OR (C)
1: f(A,B) SET (C) RESET RISING EDGE
2: f(A,B) AND (C)
3: f(A,B) XOR (C)
4: f(A,B) NOR (C)
5: f(A,B) NAND (C)
6: f(A,B)\ OR (C)
7: f(A,B) OR (C\)
8: f(A,B)\ AND (C)
9: f(A,B) AND (C\)
10: f(A,B) RESET (C) SET RISING EDGE
11: f(A,B) SET (C) RESET FALLING EDGE
12: f(A,B) RESET (C) SET FALLING EDGE
Default
0
0: f(A,B) OR (C)
Level
ADVANCED
Address
933
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
