P358 MPL1: Output Logic Level
P358 Range
0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ADVANCED
Address
958
Function
MPL1 digital output logic function to apply a logic reversal (negation) to the
calculate
d output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
P359 MPL2: Digital Output Mode
P359 Range
0 ÷ 8
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
Default
1
0: DISABLE
Level
ADVANCED
Address
959
Function
This parameter defines the operating mode of virtual digital output 2. The
different operating modes are described at the beginning of this chapter.
P360 MPL2: Selecting Variable A
P360
Range
0 ÷ 149
See Table 48
Default
33
D0: Disable
Level
ADVANCED
Address
960
Function
This parameter selects the digital signal used to calculate the value of MPL2
digital output.
It selects an analog variable used to calculate the value of MPL2
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P361 MPL2: Selecting Variable B
P361
Range
0 ÷ 149
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
961
Function
This parameter selects the second digital signal used to calculate the value of
MPL2 digital output.
It selects an analog variable used to calculate the value of MPL2
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
