P384 MPL4: Function Applied to the Result of the 2 Tests
P384 Range
0 ÷ 12
0: (A) OR (B)
1: (A) SET (B) RESET
2: (A) AND (B)
3: (A) XOR (B)
4: (A) NOR (B)
5: (A) NAND (B)
6: (A\) OR (B)
7: (A) OR (B\)
8: (A\) AND (B)
9: (A) AND (B\)
10: (A) RESET (B) SET RISING EDGE
11: (A) SET (B) RESET FALLING EDGE
12: (A) RESET (B) SET FALLING EDGE
Default
0
0: (A) OR (B)
Level
ADVANCED
Address
984
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
P384a MPL4: Selecting Variable C
P384a
Range
0 ÷79
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
938
Function
This parameter selects the digital signal used to calculate the value of
MPL4
digital output.
The digital signals that can be selected are given in Table 48.
P384b MPL4: Function Applied to the Result of f(A,B) C
P384b Range
0 ÷ 12
0: f(A,B) OR (C)
1: f(A,B) SET (C) RESET RISING EDGE
2: f(A,B) AND (C)
3: f(A,B) XOR (C)
4: f(A,B) NOR (C)
5: f(A,B) NAND (C)
6: f(A,B)\ OR (C)
7: f(A,B) OR (C\)
8: f(A,B)\ AND (C)
9: f(A,B) AND (C\)
10: f(A,B) RESET (C) SET RISING EDGE
11: f(A,B) SET (C) RESET FALLING EDGE
12: f(A,B) RESET (C) SET FALLING EDGE
Default
0
0: f(A,B) OR (C)
Level
ADVANCED
Address
939
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
