Santerno Sinus Penta - Page 247

PROGRAMMING GUIDE
SINUS PENTA
247/486
P380 MPL4: Testing Variable A
P380 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
980
Function
This parameter defines the test to be performed for the variable detected by
P378 using P382 as a comparing value.
P381 MPL4: Testing Variable B
P381 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
981
Function
This parameter defines the test to be performed for the variable detected by
P379 using P383 as a comparing value.
P382 MPL4: Comparing Value for Test A
P382 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see
Table
48
Default
0
0
Level
ADVANCED
Address
982
Function
This parameter defines the comparing value with the selected variable for test A.
P383 MPL4: Comparing Value for Test B
P383 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see
Table
48
Default
0
0
Level
ADVANCED
Address
983
Function
This parameter defines the comparing value with the selected variable for test B.
