P376 MPL3: Output Logic Level
P376 Range
0–1
0: TRUE
1: FALSE
Default
1
1: TRUE
Level
ADVANCED
Address
976
Function
MPL3 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
P377 MPL4: Digital Output Mode
P377 Range
0 ÷ 8
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
Default
1
0: DISABLE
Level
ADVANCED
Address
977
Function
This parameter defines the operating mode of virtual digital output 4. The
different operating modes are described at the beginning of this chapter.
P378 MPL4: Selecting Variable A
P378
Range
0 ÷ 149
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
978
Function
This parameter selects the digital signal used to calculate the value of MPL4
digital output.
It selects an analog variable used to calculate the value of MPL4
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P379 MPL4: Selecting Variable B
P379
Range
0 ÷ 149
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
979
Function
This parameter selects the second digital signal used to calculate the value of
MPL4 digital output.
It selects an analog variable used to calculate the value of MPL4
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
