Santerno Sinus Penta - Page 245

PROGRAMMING GUIDE
SINUS PENTA
245/486
P375 MPL3: Function Applied to the Result of the 2 Tests
P375 Range
0 ÷ 12
0: (A) OR (B)
1: (A) SET (B) RESET
2: (A) AND (B)
3: (A) XOR (B)
4: (A) NOR (B)
5: (A) NAND (B)
6: (A\) OR (B)
7: (A) OR (B\)
8: (A\) AND (B)
9: (A) AND (B\)
10: (A) RESET (B) SET RISING EDGE
11: (A) SET (B) RESET FALLING EDGE
12: (A) RESET (B) SET FALLING EDGE
Default
0
0: (A) OR (B)
Level
ADVANCED
Address
975
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
P375a MPL3: Selecting Variable C
P375a
Range
0 ÷ 79
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
936
Function
This parameter selects the digital signal used to calculate the value of MPL3
digital output.
The digital signals that can be selected are given in see Table 48.
P375b MPL3: Function Applied to the Result of f(A,B) C
P375b Range
0 ÷ 12
0: f(A,B) OR (C)
1: f(A,B) SET (C) RESET RISING EDGE
2: f(A,B) AND (C)
3: f(A,B) XOR (C)
4: f(A,B) NOR (C)
5: f(A,B) NAND (C)
6: f(A,B)\ OR (C)
7: f(A,B) OR (C\)
8: f(A,B)\ AND (C)
9: f(A,B) AND (C\)
10: f(A,B) RESET (C) SET RISING EDGE
11: f(A,B) SET (C) RESET FALLING EDGE
12: f(A,B) RESET (C) SET FALLING EDGE
Default
0
0: f(A,B) OR (C)
Level
ADVANCED
Address
937
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
