SINUS PENTA
PROGRAMMING GUIDE
244/486
P371 MPL3: Testing Variable A
P371 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
971
Function
This parameter defines the test to be performed for the variable detected by
P369 using P373 as a comparing value.
P372 MPL3: Testing Variable B
P372 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
972
Function
This parameter defines the test to be performed for the variable detected by
P370 using P374 as a comparing value.
P373 MPL3: Comparing Value for Test A
P293 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see
Table
48
Default
0
0
Level
ADVANCED
Address
973
Function
This parameter defines the comparing value with the variable selected for test A.
P374 MPL3: Comparing Value for Test B
P374 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see
Table
48
Default
0
0
Level
ADVANCED
Address
974
Function
This parameter defines the comparing value with the variable selected for test B.
