P367 MPL2: Output Logic Level
P367 Range
0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ADVANCED
Address
967
Function
MPL2 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
P368 MPL3: Digital Output Mode
P368 Range
0 ÷ 8
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
Default
1
0: DISABLE
Level
ADVANCED
Address
968
Function
This parameter defines the operating mode of virtual digital output 3. The
different operating modes are described at the beginning of this chapter.
P369 MPL3: Selecting Variable A
P369
Range
0 ÷ 149
See Table 48
Default
38
D0: Disable
Level
ADVANCED
Address
969
Function
This parameter selects the digital signal used to calculate the value of MPL3
digital output.
It selects an analog variable used to calculate the value of MPL3
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P370 MPL3: Selecting Variable B
P370
Range
0 ÷ 149
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
970
Function
This parameter selects the second digital signal used to calculate the value of
MPL3 digital output.
It selects an analog variable used to calculate the value of digital input MPL3
if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
