Santerno Sinus Penta - Page 280

SINUS PENTA
PROGRAMMING GUIDE
280/486
C013 (C056, C099) Type of V/F Pattern
C013 (Motor 1)
C056 (Motor 2)
C099 (Motor 3)
Range
0 ÷ 2
0: Constant Torque
1: Quadratic
2: Free Setting
Default
See Table 83 and Table 87
Level
BASIC
Address
1013, 1056, 1099
Control
IFD
Function
Allows selecting different types of V/f pattern.
If C013 (C056,C099) = Constant torque
, voltage at zero frequency can be
selected (Preboost C034 (C077,C120)).
If C013 (C056,C099) = Quadratic
, you can select voltage at zero frequency
(preboost, C034 (C077,C120)), max. voltage drop with respect to the theoretical
V/f
pattern, C032 (C075 C118
), and the frequency allowing implementing max. voltage
drop, C033 (C076 C119).
If C013 (C056,C099) = Free Setting
, you can set voltage at zero frequency
(preboost, C034(C077,C120
)); voltage increase to 20% of the rated frequency
(Boost0, C035 (C078,C121
)); and voltage increase to a programmed frequency
(Boost1, C036 (C079,C122); frequency for Boost1, C037 (C080,C123)).
C014 (C057, C100) Phase Rotation
C014 (Motor 1)
C057 (Motor 2)
C100 (Motor 3)
Range
0÷1 0: [No]; 1: [Yes]
Default
0
0: [No]
Level
ENGINEERING
Address
1014, 1057,1100
Function
Allows reversing the mechanical rotation of the connected motor.
DANGER!!!
When activating C014 (C057, C100), the mechanical rotation of the connected motor and
its load is reversed accordingly.
C015 (C058, C101) Rated Motor Frequency
C015 (Motor 1)
C058 (Motor 2)
C101 (Motor 3)
Range
10 ÷ 10000 1.0 Hz ÷ 1000.0 Hz
See upper limits in Table 70
Default
500
50.0 Hz
Level
BASIC
Address
1015, 1058, 1101
Control
All
Function
This parameter defines the rated motor frequency (nameplate rating).
C016 (C059, C102) Rated Motor Rpm
C016 (Motor 1)
C059 (Motor 2)
C102 (Motor 3)
Range
1 ÷ 32000 1 ÷ 32000 rpm
Default
1420
1420 rpm
Level
BASIC
Address
1016 , 1059, 1102
Function
This parameter defines the rated motor rpm (nameplate rating).
