SINUS PENTA
PROGRAMMING GUIDE
346/486
C181 Safety Start
C181
Range
0 ÷ 1
Inactive, Active
Default
0
Inactive
Level
ADVANCED
Address
1181
Function
This function enables the Safety START mode.
When this function is enabled and the drive is to be restarted after resetting an alarm,
open and close the ENABLE-A and ENABLE-B terminals.
This prevents the drive from RUNNING
when it is turned off and on again (for example
after a mains loss) and the START and ENABLE-A and ENABLE-B inputs are on.
NOTE
If multiple terminal boards are selected with parameters C140, C141, C142, open and close
the MDI2 terminals in one of the active terminal boards to restart the drive.
C182 Multiprogramming Enable
C182
Range
0 ÷ 1
Inactive, Active
Default
1
Inactive
Level
ENGINEERING
Address
1182
Function
This function allows allocating two different functions to the same terminal.
NOTE
Only few preset combinations are allowed.
When invalid configurations are set up, “ILLEGAL DATA” appears on the display/keypad of
the Penta drive.
C183 Max. Fluxing Time Before Drive Disable
C183
Range
0 ÷ 65000
0 ÷ 65000 ms
Default
0
Disabled
Level
ADVANCED
Address
1183
Control
VTC and FOC
Function
This function disables the drive if the fluxing time period is longer than the preset time (if
the ENABLE function, not a START command, is active).
To restore motor fluxing, disable and enable the ENABLE function, or
if with the active
ENABLE function a START command is also activated.
NOTE The time set in C183 is added to the Fluxing Ramp Time set in C041 / C084 / C127.
C184 Fluxing at Activation only with START Closed
C184
Range
0 ÷1
0:No - 1:Yes
Default
0
0:No
Level
ADVANCED
Address
1184
Control
VTC and FOC
Function
Fluxing may be carried out only when the START command is closed.
