PROGRAMMING GUIDE
SINUS PENTA
347/486
C184a Disable External Torque Limit During Fluxing
C184a
Range
0 ÷ 1
0:NO; 1:Yes
Default
0
0:NO
Level
ENGINEERING
Address
1200
Control
FOC
Function
During the fluxing stage, until the desired flux value is attained, the external torque
limit (if any) set in C147 is disabled (see CONTROL METHOD MENU
). During that
stage, only the limits set in C047 and C048 (see LIMITS MENU) are applied.
This function is useful to limit undesired motor operation—
due to residual rotor
magnetization—during the fluxing stage.
C185 STOP Mode
C185
Range
0 ÷1
0: [Deceleration Ramp] – 1:[Free Wheel]
Default
0
0: [Deceleration Ramp]
Level
ADVANCED
Address
1185
Function
This function allows selecting whether the drive is to be deactivated with a controlled
deceleration ramp or is left idling when the START command is open.
C186 Fire Mode Enable Input
C186 Range
0 ÷ 16
0 ÷
24 if ES847 or ES870 is
fitted
0 → Inactive
1 ÷ 8 → MDI1 ÷ MDI8
9 ÷ 12 → MPL1 ÷ MPL4
13 ÷ 16 → TFL1 ÷ TFL4
17 ÷ 24 → XMDI1 ÷ XMDI8
Default
0
Inactive
Level
ENGINEERING
Address
1186
Function
This parameter allows programming a digital input to activate the Fire Mode (see the
Fire Mode section).
C187 Torque Limit Source Ref. Disable Input
C187 Range
0 ÷ 16
0 ÷ 24 if ES847 or ES870 is
fitted
0 → Inactive
1 ÷ 8 → MDI1 ÷ MDI8
9 ÷ 12 → MPL1 ÷ MPL4
13 ÷ 16 → TFL1 ÷ TFL4
17 ÷ 24 → XMDI1 ÷ XMDI8
Default
0
Inactive
Level
ADVANCED
Address
1187
Function
This function sets a digital input allowing disabling the external torque limit. When the
digital input set for C187
is active, the torque limit will depend on the parameters
contained in the LIMITS MENU of the active motor.
