C300/C300a Pretensioning Torque [%Cmot]
Function
If not set to zero, this parameter defines the torque value (expressed as a
percentage of the rated torque of the selected motor) reached before the
speed ramp starts after sending a START command.
After sending a START command, the drive b
rings the motor torque to the
level set in C300/C300a
and torque is adjusted by the speed loop for the time
set in C301/C301a
in order to keep the motor standstill. Once this time has
elapsed, the speed ramp can start and the motor follows the required spe
profile.
The torque sign defines the running direction.
The sign of the speed reference determines which value percent is to be
used; C300 is for the positive sign, C300a is for the negative sign.
C301/C301a Pretensioning Torque Time
Function
Delay time passing between the start command and the speed ramp start.
During this time, the motor torque output is set in C300/C300a to keep the
C302 Closed Brake Input (NO contact)
C302 Range
0 ÷ 12
0 ÷
installed
0 → Inactive
1 ÷ 8 → MDI1 ÷ MDI8
9 ÷ 12 → MPL1 ÷ MPL4
13 ÷ 16 → TFL1 ÷ TFL4
17 ÷ 24 → XMDI1 ÷ XMDI8
Function
This parameter determines the digital input assigned to the mechanical
brake closure feedback (NO contact, which closes only when the brake is
engaged). When the brake closure is detecte
d after a deceleration ramp,
the current required for motor fluxing is injected into the motor. If no digital
input is available for the detection of the brake closure, set max. time in
C183, in order to avoid injecting current into the motor after the dec
ramp. When the motor is not running, the START
the speed setpoint is at zero for a time longer than the one set in C183
, the
drive will be put on standby.
