Santerno Sinus Penta - Page 411

PROGRAMMING GUIDE
SINUS PENTA
411/486
C303 Brake Activation during Tracking Error
C303 Range
0 ÷ 1
0: No
1: Yes
Default
1
1: Yes
Level
ENGINEERING
Address
1304
Control
VTC and FOC
Function
This parameter defines if, in case of tracking error (ENCODER/FREQUENCY
INPUTS MENU, parameters C192, C193, C194), t
he output of the
electromechanical brake is to be disabled, thus causing the activation of the
brake itself.
0: No, in case of tracking error, the brake command output is kept active.
1: Yes, in case of tracking error, the brake command output is deactivat
ed, thus
causing the brake activation.
If C194=1 (or =2 in some cases), the tracking error triggers alarm A080. In cas
e
of alarm, the brake output is disabled, independently of the value in C303.
