PROGRAMMING GUIDE
SINUS PENTA
427/486
R004 Time added to 4–Byte–Time for Serial Link 0 (D9-pole)
R004
Range
1 ÷ 10000
1 ÷ 10000 msec
Default
2
2 msec
Level
ENGINEERING
Address
591
Function
This parameter determines the limit time when no character is received from serial
link 0 (9-
pole, male D connector) and the message sent from the master to the
drive is considered as complete.
R005 Watchdog Time for Serial Link 0 (D9-pole)
R005
Range
0 ÷ 60000
0 ÷ 6000.0 sec
Default
0
0.0 sec
Level
ENGINEERING
Address
592
Function
If not set at zero, this parameter determines the time limit after which alarm A061
WDG Serial 0 Alarm
trips if the drive does not receive any legal message through
serial link 0 (9-pole, male D connector).
R006 Parity Bit for Serial Link 0 (D9-pole)
R006 Range
0 ÷ 3
0: Disabled 1 Stop–bit
1: Disabled 2 Stop–bit
2: Even (1 Stop bit)
3: Odd (1 Stop bit)
Default
1
1: Disabled 2 Stop–bit
Level
ENGINEERING
Address
593
Function
This parameter determines whether the parity bit is used or not when creating the
MODBUS message through serial link 0 (9-pole, male D connector).
R008 Drive MODBUS Address for Serial Link 1 (RJ45)
R008
Range
1 ÷ 247
1 ÷ 247
Default
1
1
Level
ENGINEERING
Address
595
Function
This parameter determines the address assigned to the drive connected to the
network through RS485 of serial link 1 (RJ45 connector).
NOTE
The display/keypad connected through RJ45 connector dialogues correctly with the drive
using the default values preset in the parameter set for serial link 1 (RJ45).
R009 Response Delay for Serial Link 1 (RJ45)
R009
Range
1 ÷ 1000
1 ÷ 1000 msec
Default
5
5 msec
Level
ENGINEERING
Address
596
Function
This parameter determines the drive response delay after a master query sent
through serial link 1 (RJ45 connector).
