Santerno Sinus Penta - Page 428

SINUS PENTA
PROGRAMMING GUIDE
428/486
R010 Baud Rate for Serial Link 1 (RJ45)
R010 Range
1 ÷ 7
1: 1200 bps
2: 2400 bps
3: 4800 bps
4: 9600 bps
5: 19200 bps
6: 38400 bps
7: 57600 bps
Default
6
6: 38400bps
Level
ENGINEERING
Address
597
Function
This parameter determines the baud rate, expressed in bits per second, for serial
link 1 (RJ45 connector).
R011 Time Added to 4–Byte–Time for Serial Link 1 (RJ45)
R011
Range
1÷10000
1 ÷ 10000 msec
Default
2
2 msec
Level
ENGINEERING
Address
598
Function
This parameter determines the time limit when no character is received from serial
link 1 (RJ45 connector) and the message sent from the master to the drive is
considered as complete.
R012 Watchdog Time for Serial Link 1 (RJ45)
R012
Range
0 ÷ 60000
0 ÷ 6000.0 sec
Default
0
0.0 sec
Level
ENGINEERING
Address
599
Function
If this parameter is not set at zero, it determines the time limit after which alarm
A062 WDG Serial Link 1 Alarm trips if the drive does not
receive any legal message
through serial link 1 (RJ45 connector).
R013 Parity Bit for Serial Link 1 (RJ45)
R013 Range 0 ÷ 3
0: Disabled 1 Stop–bit
1: Disabled 2 Stop–bit
2: Even (1 Stop bit)
3: Odd (1 Stop bit)
Default
1
1: Disabled 2 Stop–bit
Level
ENGINEERING
Address
600
Function
This parameter determines whether the parity bit is used or not when creating the
MODBUS message through serial link 1 (RJ45 connector).
