PAR.-Meaning Default Values Modified values PAR.-Meaning Default Values Modified values
P21x-P22x Timers
P216-T1 delay On
0.0 s
P217-T1 delay Off
0.0 s
P218-T2 delay On
0.0 s
P219-T2 delay Off
0.0 s
P220-T3 delay On
0.0 s
P221-T3 delay Off
0.0 s
P222-T4 delay On
0.0 s
P223-T4 delay Off
0.0 s
P224-T5 delay On
0.0 s
P225-T5 delay Off
0.0 s
P226a-Timer MDI1
0
P226b-Timer MDI2
0
P226c-Timer MDI3
0
P226d-Timer MDI4
0
P227a-Timer MDI5
0
P227b-Timer MDI6
0
P227c-Timer MDI7
0
P227d-Timer MDI8
0
P228a-Timer MDO1
0
P228b-Timer MDO2
0
P228c-Timer MDO3
0
P228d-Timer MDO4
0
P229a-Timer MPL1
0
P229b-Timer MPL2
0
P229c-Timer MPL3
0
P229d-Timer MPL4
0
P23x-P26x PID Parameters
P236-PID Out Max
100.00 %
P237-PID Out Min
100.00 %
P237a-Wake Up Mode 0: Disabled
P237b-Wake Up
Level
0.00 %
P238-Integ Max
100.00 %
P239-Der Max
100.00 %
P240-PID Kp
1.000
P241-PID KpMult
0: 1
P242-PID Ti(Tc)
500 Tc
P243-PID Td(Tc)
0 mTc
P244-PID Tc
5 ms
P245-PID Ref Min
0.00 %
P246-PID Ref Max
100.00 %
P247-PID Fdbk Min
0.00 %
P248-PID Fdbk Max
100.00 %
P249-PID Tup
0.00 s
P250-PID Tdn
0.00 s
P251-PID U.Mea.
1: 0.1 s
P252-Rnd start
50 %
P253-Rnd stop
50 %
P254-Thresh Int
0.0 %|Refmax|
P255-Disab Time
Disabled
P256-Trate Lim
1 ms
P257-GainScale
1.000
P260-GainAWUP
1.00
P27x-P30x Digital Outputs
P270-Out1Mode
3: Analog
P271-Out1Sel1
A71: Speed
P272-Out1Sel2
A71: Speed
P273-Out1 Test1
0: >
P274-Out1 Test2
3: ≤
P275-D01 ValTst1
50.000 rpm
P276-D01 ValTst2
10.000 rpm
P277-Out1Func
1: (A) Set (B) Reset
P277a-Out1Sel1
D0: Disable
P277b-Out1Func
0: f(A,B) OR (C)
P278-Out1Logic
1: True
P279-Out2Mode
6: Brake
P280-Out2Sel1
A81: Torque output
P281-Out2Sel2
A71: Speed
P282-Out2 Test1
0: >
P283-Out2 Test2
3: ≤
P284-D02 ValTst1
20.000 %
P285-D02 ValTst2
50.000 rpm
P286-Out2Func
1: (A) Set (B) Reset
P286a-Out2Sel1
D0: Disable
P286b-Out2Func
0: f(A,B) OR (C)
P287-Out2Logic
1: True
P288-Out3Mode
1: Digital
P289-Out3Sel1
D3: Inverter Alarm
P290-Out3Sel2
D3: Inverter Alarm
P291-Out3 Test1
0: >
P292-Out3 Test2
0: >
P293-D03 ValTst1
0.000
P294-D03 ValTst2
0.000
P295-Out3Func
0: (A) OR (B)
P295a-Out3Sel1
D0: Disable
P295b-Out3Func
0: f(A,B) OR (C)
P296-Out3Logic
0: False
P297-Out4Mode
1: Digital
P298-Out4Sel1
D1: Inverter Run Ok
P299-Out4Sel2
D1: Inverter Run Ok
P300-Out4 Test1
0: >
P301-Out4 Test2
0: >
P302-D04 ValTst1
0.000
P303-D04 ValTst2
0.000
P304-Out4Func
0: (A) OR (B)
P304a-Out4Sel1
D0: Disable
P304b-Out4Func
0: f(A,B) OR (C)
P305-Out4Logic
1: True
