PAR.-Meaning Default Values Modified values PAR.-Meaning Default Values Modified values
P306-P317 Aux Digital Outputs
P306-Out1Sel
D0: Disable
P307-Out1Logic
1: True
P308-Out2Sel
D0: Disable
P309-Out2Logic
1: True
P310-Out3Sel
D0: Disable
P311-Out3Logic
1: True
P312-Out4Sel
D0: Disable
P313-Out4Logic
1: True
P314-Out5Sel
D0: Disable
P315-Out5Logic
1: True
P316-Out6Sel
D0: Disable
P317-Out6Logic
1: True
P32x PT100 Settings
P320-Mea1 Type
0:Disable
P321-Offset Mea1
0
P322-Mea2 Type
0:Disable
P323-Offset Mea2
0
P324-Mea3 Type
0:Disable
P325-Offset Mea3
0
P326-Mea4 Type
0:Disable
P327-Offset Mea4
0
P33x Fieldbus Parameters
P330-fbs_meas3 M012 Torq.Out.% P331-fbs_meas4 M022 PID Out%
P35x-P38x MPL
P350-Out1Mode
0: Disable
P351-Out1Sel1
D0: Disable
P352-Out1Sel2
D0: Disable
P353-Out1 Test1
0: >
P354-Out1 Test2
0: >
P355-D01 ValTst1
0
P356-D01 ValTst2
0
P357-Out1Func
0: (A) OR (B)
P357a-Out1Sel1
D0: Disable
P357b-Out1Func
0: f(A,B) OR (C)
P358-Out1Logic
1: True
P359-Out2Mode
0: Disable
P360-Out2Sel1
D0: Disable
P361-Out2Sel2
D0: Disable
P362-Out2 Test1
0: >
P363-Out2 Test2
0: >
P364-D02 ValTst1
0
P365-D02 ValTst2
0
P366-Out2Func
0: (A) OR (B)
P366a-Out2Sel1
D0: Disable
P366b-Out2Func
0: f(A,B) OR (C)
P367-Out2Logic
1: True
P368-Out3Mode
0: Disable
P369-Out3Sel1
D0: Disable
P370-Out3Sel2
D0: Disable
P371-Out3 Test1
0: >
P372-Out3 Test2
0: >
P373-D03 ValTst1
0
P374-D03 ValTst2
0
P375-Out3Func
0: (A) OR (B)
P375a-Out3Sel1
D0: Disable
P375b-Out3Func
0: f(A,B) OR (C)
P376-Out3Logic
1: True
P377-Out4Mode
0: Disable
P378-Out4Sel1
D0: Disable
P379-Out4Sel2
D0: Disable
P380-Out4 Test1
0: >
P381-Out4 Test2
0: >
P382-D04 ValTst1
0
P383-D04 ValTst2
0
P384-Out4Func
0: (A) OR (B)
P384a-Out4Sel1
D0: Disable
P384b-Out4Func
0: f(A,B) OR (C)
P385-Out4Logic
1: True
P39x Auxiliary Reference
P390-XAIN4
3: 0-10V
P391-XAIN4MIN
0.0 V
P391a-XAIN4MIN_%
100%
P392-XAIN4MAX
10.0 V
P392a-XAIN4MAX_%
100%
P393-XAIN4OFFS
0.000 V
P394-TauFilt XAIN4
100 ms
P395-XAIN5
2: 4-20mA
P396-XAIN5MIN
4.0 mA
P396a-XAIN5MIN_%
100%
P397-XAIN5MAX
20.0 mA
P397a-XAIN5MAX_%
100%
P398-XAIN5OFFS
0.000 mA
P399-TauFilt XAIN5
100 ms
P43x-P46x PID2 Parameters
P436-PID2 Out Max
100.00 %
P437-PID2 Out Min
100.00 %
P437a-Wake Up Mode
0: Disabled
P437b-Wake Up Level
0.00 %
P438-Integ Max
100.00 %
P439-Der Max
100.00 %
P440-PID2 Kp
1.000
P441-PID2 KpMult
0: 1
P442-PID2 Ti(Tc)
500 Tc
P443-PID2 Td(Tc)
0 mTc
P444-PID2 Tc
5 ms
P445-PID2 Ref Min
0.00 %
P446-PID2 Ref Max
100.00 %
P447-PID2 Fdbk Min
0.00 %
P448-PID2 Fdbk Max
100.00 %
P449-PID2 Tup
0.00 s
P450-PID2 Tdn
0.00 s
P451-PID2 U.Mea.
1: 0.1 s
P452-Rnd start
50 %
P453-Rnd stop
50 %
P454-Thresh Int
0.0 %|Refmax|
P455-Disab Time
Disabled
P456-Trate Lim
1 ms
P457-GainScale
1.000
P460-GainAWUP
1.00
