Santerno Sinus Penta - Page 62

SINUS PENTA
PROGRAMMING GUIDE
62/486
M039b XAIN5 External Analog Reference
M039b Range
Function of the preset type of
reference.
Function of the type of reference (current) set in P395.
The numerical value always includes two decimals; the
unit of measure is mA.
Active
Active only if set via parameter R023.
Address
1730
Function
Measure of the current value detected by the drive in the XAIN5 analog input.
M040 Speed Reference from Serial Link
M040 Range
± 32000
(integer part)
±
99 (decimal
part)
± 32000.99 rpm
Note:
The actual range depends on the selected motor, because it is defined
by the value set in the parameters for the max. speed and min. speed of the
selected motor.
C028–C029 Motor 1
C072–C073 Motor 2
C114–C115 Motor 3
Active
Always active.
Address
1690 (integer part), 1691 (decimal part)
Function
This is the value of the speed reference set via serial link.
M042 Speed Reference from Fieldbus
M042 Range
± 32000
(integer
part)
± 99
(decimal
part)
± 32000.99 rpm
Note:
The actual range depends on the selected motor, because it is defined by
the value set in the parameters for the max. speed and min. speed of the
selected motor.
C028–C029 Motor 1
C072–C073 Motor 2
C114–C115 Motor 3
Active
Always active.
Address
1692 (integer part), 1693 (decimal part)
Function
This is the measure of the speed reference set by the fieldbus.
M044 Torque Reference from Serial Link
M044 Range
± 5000
± 500.0 %
Note: The actual r
ange depends on the torque limit value set for the selected
motor.
C047–C048 Motor 1
C090–C091 Motor 2
C133–C134 Motor 3
Active
Always active.
Address
1694
Function
This is the measure of the torque reference set via serial link and expressed as a pe
rcentage
of the rated torque of the selected motor.
