Chapter 9: CONNECTIONS
6. CONNECTION CABLE PIN ASSIGNMENT
9-20
•DirectpowersupplyfromtheVX-2000DSorVX-3000DStotheRM-200XF
LINK
DC POWER IN
24V
MICSP
EXTERNAL
MIC IN
RM-200X Rear
RJ45 connector
Pin No.
RJ45 connector
Pin No.
To VX-200XR
Plug-in screw terminal
(supplied with the RM-200XF)
1
2
5
6
3
4
7
8
Shield
1
2
5
6
3
4
7
8
Shield
To the next
RM-200X
Monitor in (H)
Monitor in (C)
RM data
Audio out (H)
Audio out (C)
RM data
DC power in (+)
DC power in (–)
Shield
–
+
From VX-2000DS'
or VX-3000DS'
DC POWER OUT
These lines supply power from the VX-200XR
to the next Remote Microphone.
RM-200XF Bottom
