Audi A8 2003 User Manual

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ Glove compartment
♦ Glove compartment bolts
♦ Bolts -2- and -3- for securing knee airbag
WARNING
Always replace the cover -1- following removal.
– When fitting, start by engaging the cover -1- at the top.
– Then clip on the cover -1- at the bottom.
– Make sure the connector for the knee airbag is heard to fully
engage with the coupling.
WARNING
There must not be anyone in the vehicle when connecting the
battery.
– With the ignition switched on, connect the battery earth wire
⇒ Electrical system; Rep. gr. 27 .
Note
If the airbag warning lamp -K75- indicates a fault following instal‐
lation, the event recorder must be interrogated, erased and inter‐
rogated again ⇒ Vehicle diagnostic tester.
Tightening torques
♦ Bolt -2-: 2.5 Nm
♦ Bolt -3-: 2.5 Nm
♦ Cover to glove compartment: 2.5 Nm
8.3 Removing and installing deformation el‐
ement for driver's knee airbag
Special tools and workshop equipment required
Audi A8 2003 ➤
General body repairs, interior - Edition 07.2011
152 Rep. gr.69 - Passenger protection
