♦ Removal wedge - 3409-
Removing
– Carefully separate the trim panel -1- from the dash panel using
the removal wedge -3409- -arrows-.
Installing
Install in reverse order.
3.3 Removing and installing trim panel with
switch module on right
Special tools and workshop equipment required
♦ Removal wedge -3409-
Removing
– Open the coin tray.
– Slide the trim for the coin tray to the left out of the fastener
-arrow- and detach.
