1.34 Removing and installing seat ventilation
unit (seat pan)
Removing
Remove the seat ⇒ page 282 .
Attach the holder for seat repair -VAS 6136- to the engine and
gearbox holder -VAS 6095- .
Attach the front seat to the holder for seat repair -VAS 6136- .
Unplug the connector -2-.
Unscrew the bolts -1- (3x). 0.5 Nm.
Detach the seat ventilation unit -3-.
Installing
Install the seat ventilation unit -3- in the reverse order of re‐
moval.
1.35 Removing and installing seat ventilation
unit (backrest)
Note
The rubber guide -1- is stitched to the padding -2-. The padding
must be replaced if the rubber guide is defective.
Removing
Remove the seat ⇒ page 282 .
Attach the holder for seat repair -VAS 6136- to the engine and
gearbox holder -VAS 6095- .
Attach the front seat to the holder for seat repair -VAS 6136- .
Remove the upper backrest cover panel ⇒ page 309 .
Remove the lower backrest cover panel ⇒ page 310 .
Unplug the connector -4-.
Press the cover -6- aside.
Drill out the rivets -5- (2x).
Detach the seat ventilation unit -3-.
Installing
Install the seat ventilation unit -3- in the reverse order of re‐
moval.
