1.14 Removing and installing seat adjust‐
ment switch
– Remove the seat ⇒ page 282 .
– Attach the holder for seat repair -VAS 6136- to the engine and
gearbox holder -VAS 6095- .
– Attach the front seat to the holder for seat repair -VAS 6136- .
– Remove the seat side trim on the sill panel side ⇒ page 292 .
– Detach the seat adjustment switch controls.
– Unfasten the cable tie -7-.
– Unplug the connector -1-.
– Unscrew the bolts -6- (3x).
♦ Tightening torque 1.5 Nm
– Detach the seat adjustment switch -2-.
1.15 Removing and installing switch for 4-
way lumbar support
– Remove the seat ⇒ page 282 .
– Attach the holder for seat repair -VAS 6136- to the engine and
gearbox holder -VAS 6095- .
– Attach the front seat to the holder for seat repair -VAS 6136- .
– Remove the seat side trim on the sill panel side ⇒ page 292 .
– Unplug the connector -4-.
– Unscrew the bolts -5- (3x).
♦ Tightening torque 0.4 Nm.
– Detach the 4-way lumbar support switch -3-.
1.16 Removing and installing seat and steer‐
ing column adjustment control unit with
memory -J136- / front passenger seat
adjustment with memory control unit -
J521-
Note
♦ If possible: Move the seat upwards and to the rear as far as it
will go.
♦ For emergency power supply for the seat longitudinal and seat
height adjustment motors ⇒ refer to Page ⇒ page 285 .
Audi A8 2003 ➤
General body repairs, interior - Edition 07.2011
1. Front seats (memory seat, electrically operated seat) 295
