Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Press on lower edge of trim -3- to engage lugs -1- in spring
clips -2-.
2.8 Removing and installing cigarette lighter
(front)
Cigarette lighter -2- installed in front ashtray -1- cannot be re‐
newed separately.
If defective, renew cigarette lighter together with front ashtray.
Removing and installing ashtray (front) ⇒ page 31
2.9 Removing and installing trim for centre
console with multimedia operating unit
Removing
Switch off ignition.
Remove ashtray (front) ⇒ page 31 .
Removing trim for centre console with multimedia operating unit
Lift trim for centre console -3- with multimedia operating unit
-4- and front centre console cup holder -5- off centre console
-1-.
6 - Spring clip
Unplug electrical connectors.
Detach trim for centre console with multimedia operating unit
and front centre console cup holder.
Remove multimedia operating unit ⇒ Rep. gr. 91 .
Audi A8 2003 ➤
General body repairs, interior - Edition 07.2011
2. Removing and installing centre console without extension 33
