Cisco ASR 1004 Hardware Installation Guide

Security Traffic
Performance
BandwidthPerformanceMemoryEmbedded Services
Processor
40 Gbps200 Gbps
•
Quad
Quantum
Flow packet
processor
complex:
◦
2 GB
total
packet
buffer
◦
8 GB
total
resource
memory
•
Dual 80MB
TCAM4
feature lookup
memory
•
32GB of
1066MHz
DDR3
SDRAM:
◦
Four
8GB,
2-rank
registered
DIMMs
Cisco
ASR1000-ESP200
1
While both the Cisco ASR1000-ESP40 and ASR1000-ESP20 exceed the 16 Mpps forwarding rate, the ESP40 packets per second rate is slightly less than
ESP20 when sending continuous stream of small, 64-byte packets. However, at 92 bytes and larger, the ASR1000-ESP40 outperforms ESP20. The difference
at small packet sizes is a side-effect of optimizations made to achieve 40 Gbps for medium to large packets.
For unsupported hardware component configuration combinations, see xref Table 2-4.Note
The embedded services processor consists of a front panel label for indicator and control functions. The Cisco
ASR 1000 Series Embedded Services Processor model number labeling is located next to the left card module
handle. The module also contains card handles to assist in insertion or removal of the module. There are no
front panel interfaces on the Cisco ASR1000-ESP modules.
The following figure displays the Cisco ASR 1000 Series Embedded Services Processor LEDS on the front
panel.
Cisco ASR 1000 Series Router Hardware Installation Guide
97
Cisco ASR 1000 Series Routers Embedded Services Processors
Features of the Cisco ASR 1000 Series Embedded Services Processors

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
