Cisco ASR 1004 Hardware Installation Guide

Behavior DescriptionColorLEDLED Label
System failure or
powering up.
Red
The ACTV LED indicates
(in a redundant system)
the embedded services
processor board that is
actively forwarding
packets.
On the active embedded
services processor board,
the ACTV LED is green
and the STBY LED is off.
On the standby embedded
services processor board,
the STBY LED is yellow
and the ACTV LED is
off.
On Cisco ASR 1002
Router, Cisco ASR 1004
Router, and Cisco ASR
1002-F Router, the
embedded services
processor board is always
active because these
routers do not support
redundancy. The Cisco
ASR1000-ESP5 does not
support redundancy.
Therefore, it is always
active.
GreenActiveACTV
On a redundant system,
the STBY LED indicates
which embedded services
processor is in the
standby state and is
waiting to take over
packet forwarding in the
event that the active
embedded services
processor experiences a
failure. The STBY LED
is in the off state while
the active embedded
services processor is in
the on state.
YellowStandbySTBY
Cisco ASR 1000 Series Router Hardware Installation Guide
99
Cisco ASR 1000 Series Routers Embedded Services Processors
Features of the Cisco ASR 1000 Series Embedded Services Processors

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
