DETAILED STEPS
Step 1
At the rear of the router, ensure that the power Standby switch is in the Standby position.
Step 2
Ensure that the positive and negative leads are disconnected from the site power source and the source circuit breaker
is turned off.
Step 3
Using a wire stripper, strip the recommended amount of wire insulation, which is 1.5 cm (0.6 inch) from the negative,
positive, and ground leads.
The stripping length is common to all types of wire
used.
Note
Figure 169: Stripping Wire for the +24 VDC Terminal Block, on page 360 shows the wire strip and lead.
Figure 169: Stripping Wire for the +24 VDC Terminal Block
——
Lead wire stripping area1
Remove the covering from exactly the specified length of each wire. If you strip too much of the covering,
exposed wire protruding from the terminal block will create an electrical hazard. If you strip too little of the
covering, the wire might not make a good contact with the terminal, or it might not be held securely in place
in the terminal.
Danger
Step 4
Using a 3.5mm screwdriver, insert the screwdriver at an angle to release the spring while you install the stripped lead
wire as shown in Figure 170: Inserting a Screwdriver Into the +24 VDC Power Supply Terminal Block, on page 360.
Figure 170: Inserting a Screwdriver Into the +24 VDC Power Supply Terminal Block
Step 5
Carefully push the screwdriver at a forward angle until you relieve the spring contact.
Step 6
With the screwdriver still inserted, gently push the lead wire (ground lead first) in until the copper wire, as shown in
Figure 171: Cisco ASR 1002-X Router +24 VDC Power Supply Lead Wire Inserted into Terminal Block, on page 360,
is no longer visible (see Figure 172: Cisco ASR 1002-X Router +24 VDC Power Supply Lead Wire Fully Inserted, on
page 361).
Ensure that no copper portion of the lead wire is exposed. Only the wire insulation should visible.Caution
Do not install wire into a terminal block that has not had its insulation removed.Caution
Figure 171: Cisco ASR 1002-X Router +24 VDC Power Supply Lead Wire Inserted into Terminal Block
Copper wire2Lead wire insulation1
Cisco ASR 1000 Series Router Hardware Installation Guide
360
Cisco ASR 1002-X Router Overview and Installation
Connecting the +24 VDC Power Supply to the Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
