Cisco ASR 1004 Hardware Installation Guide

Table 11: Cisco ASR 1000 Series Route Processor Connectors
DescriptionTypeLabel
A recessed button to cut off the
audible alarm. This is triggered
when the critical, major, or minor
LED is set.
Audible Cutoff buttonACO
Side-by-side USB connector used
with memory sticks or smart cards
for secure key distribution
USB0 interface0
Side-by-side USB connector used
with memory sticks or smart cards
for secure key distribution
USB1 interface1
Indicates BITS timing reference.RJ-45 connectorBITS
The route processor has an ENET
port with a RJ-45 connector to
attach a management device or
network for network management.
One RJ-45 jack for copper Ethernet
Management Port
MGMT ETHERNET
Console port used to connect to a
terminal.
One RJ-45 for CON/AUXCON
Auxiliary port used for remote
management purposes.
One RJ-45 for CON/AUXAUX
Out of Band (OOB) or modem connection in the AUX and/or CON ports, regardless of being properly
configured, the connection is not established and a call cannot be setup. This functionality is not supported
on any of the Cisco ASR 1000 Series Aggregation Services Routers or on any of the Cisco IOS XE
versions.
Note
The Cisco ASR 1000 Series Route Processor meets the following requirements:
•
Supports up to 4 GB of memory with single-bit error correction and multi-bit error detection (except
for the Cisco ASR 1002 embedded route processor)
•
Supports On-board Failure Logging (OBFL) with 2MB of memory
•
Supports the Cisco ASR 1000 Series Router system architecture and midplane
•
Enhanced Serdes Interconnect (ESI) at 11.5 Gbps.
•
Gigibit Ethernet switches for EOBC communication and boot-up of the Cisco ASR 1000 Series SPA
Interface (SIP) and Cisco ASR 1000 Series Embedded Services Processor.
•
Runs Cisco IOS network control plane (routing protocol, connections setup)
Cisco ASR 1000 Series Router Hardware Installation Guide
42
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1000 Series Route Processor Differences

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
