Behavior Description
Color —State
LEDLED Label
Minor alarm indicator.
Ambient air temperature
is beyond normal
operating range of 40ºC.
For example: if the RP
software determines that
an unknown card has
been installed or if the
card has failed, the card
can power it off or set a
minor alarm.
AmberMinorMIN
Activity indicator.Flashing GreenInternal hard drive LEDDISK HD
No activity.Off
Activity indicator.Flashing GreenExternal USB Flash
LED
DISK USB
No activity.Off
Activity indicator.Flashing GreenInternal USB bootflash
LED
DISK BF
No activity.Off
Out of service or not
configured.
OffLEDBITS I/F Mode
CARRIER
In frame and working
properly.
Solid Green
Fault or loop condition
exists.
Amber
Warmup, Free-run, or
Holdover.
OffLEDDTI ModeCARRIER
for Cisco ASR1000-RP2
Normal or bridging.Solid Green
Fast.Amber
Link with no activity.Solid Green10/100/1000 RJ-45
Interface LED
LINK
Link with Activity.Flashing Green
No link.Off
The following table lists the Cisco ASR 1000 Series Route Processors connectors and description.
Cisco ASR 1000 Series Router Hardware Installation Guide
41
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1000 Series Route Processor Differences

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
