Comtech EF Data CDM-625 - Page 529

CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–59
D.5.9 LNB Parameters (L-Band Device)
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
LNB
DC Power
Control
LPS=
Exception –
600L Emulation:
LNB & LNV
1 byte
Command or Query.
LNB DC Power Supply Control, in the form x, where:
0 = OFF
1 = 13V LNB Voltage
2 = 18V LNB Voltage
3 = 24V LNB Voltage
LPS=
LPS?
LPS*
LPS#
LPS?
Exception –
600L Emulation:
LNB & LNV
LPS=x
(see Description of
Arguments)
LNB
Reference
Enable
LNR=
1 byte, value
of 0 or 1
Command or Query.
LNB Reference Enable, in the form x, where:
0 = Disable LNB Reference
1 = Enable LNB Reference
LNR=
LNR?
LNR*
LNR#
LNR?
LNR=x
(see Description of
Arguments)
LNB
Low Current
Limit
LNL=
3 bytes
Command or Query.
Low Current Limit in the form xxx, where xxx is a value between 0 and 500 mA.
LNL=
LNL?
LNL*
LNL#
LNL?
LNL=xxx
(see Description of
Arguments)
LNB
High Current
Limit
LNH=
3 bytes
Command or Query.
High Current Limit in the form xxx, where xxx is a value between 0 and 500 mA.
LNH=
LNH?
LNH*
LNH#
LNH?
LNH=xxx
(see Description of
Arguments)
LNB
Current
N/A
4 bytes
Query only.
LNB Current in the form xxxx, where the value is in mA.
N/A
LNC?
LNC=xxxx
(see Description of
Arguments)
LNB
Voltage
N/A
4 bytes
Query only.
LNB Voltage in the form xxxx, where the value is in volts.
N/A
LVO?
LVO=xxxx
(see Description of
Arguments)
