CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–60
D.5.10 Ethernet Parameters
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Ethernet
Control
SEC=
31 bytes
Command or Query.
In the form 1abbbbc;2abbbbc;3abbbbc;4abbbbc, where:
1, 2, 3, 4 is port number.
a = reserved, default to 1.
bbbb = reserved, default to 0001.
c = port speed:
0 = Auto
1 = 100 Full
2 = 100 Half
3 = 10 Full
4 = 10 Half.
SEC=
SEC?
SEC*
SEC#
SEC?
SEC=1abbbbc;2ab
bbbc;3abbbbc;4abb
bbc
(see Description of
Arguments)
Actual
Negotiated
Port Speed
N/A
None
Query only.
In the form abcd, where:
a = port 1 negotiated port speed.
b = port 2 negotiated port speed.
c = port 3 negotiated port speed.
d = port 4 negotiated port speed.
a, b, c, d have the following values:
0 = Link down
1 = 100 Full
2 = 100 Half
3 = 10 Full
4 = 10 Half
N/A
NPS?
NPS=abcd
(see Description of
Arguments)
WAN Buffer
Length
WBL=
3 bytes
Command or Query.
WAN Buffer Length, 20 to 780 milliseconds, in 20 milliseconds steps.
Example: WBL=100
WBL=
WBL?
WBL*
WBL#
WBL?
WBL=xxx
(see Description of
Arguments)
Average WAN
Buffer Fill
State
N/A
2 bytes
Query only.
Returns the value of Average WAN buffer fill state, between 0 and 99%.
Example: WBF=33 (selects 33%)
N/A
WBF?
WBF=xx
(see Description
of Arguments)
