CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–61
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Ethernet
Global
Configuration
EGC=
Up to 347
bytes
Command or Query.
Global Configuration of CDM625 Ethernet, in the form shown in the Response to Query column, where:
EGC=
EGC?
EGC*
EGC#
EGC?
EGC?n (where n
= 0 to 9. Returns
the EGC portion
of 1 of 10 stored
configurations)
EGC=1abccccdxxx;2
abccccdxxx;3abcccc
dxxx;4abccccdxxxD
EFFGHIJKKKKLLLL
….
(see Description of
Arguments)
1abccccdxxx;2abccccdxxx;3abccccdxxx;4abccccdxxx=Switch Ports configuration
D=VLAN Mode Enable
E=Switch MAC Learning
FF=QoS Priority
G= Ethernet 2048 Frame Size
H= Precision Time Protocol Feature
I= Precision Time Protocol Mode
J= Carrier ID
KKKK=Management VLAN ID
LLLL….=VLAN Table
same as SPC
same as SVM
same as SML
same as QOS
same as EFS
same as PTP
same as PTM
same as CAI
same as SMV
same as SVT
VLAN Mode
Enable
SVM=
1 byte, value
0 or 1
Command or Query.
VLAN Mode Enable, in the form x, where:
0 = VLAN is Disabled
1 = VLAN is Enabled
SVM=
SVM?
SVM*
SVM#
SVM?
SVM=x
(see Description of
Arguments)
Switch MAC
Learning
SML=
1byte, value
0 or 1
Command or Query.
Switch MAC learning in the form x, where:
0 = Off
1 =On
SML=
SML?
SML*
SML#
SML?
SML=x
(see Description of
Arguments)
VLAN Table
SVT=
Up to 287
byes
Command or Query.
Sets/Returns all the entries in the VLAN table in the form aaaabcde,aaaabcde,aaaabcde,…, where:
aaaa = VLAN ID. Value range is 1-4095, must not be duplicate of any PVID.
b = property of port 1: 0=Tagged, 1=Filtered, 2=Untagged
c = property of port 2: 0=Tagged, 1=Filtered, 2=Untagged
d = property of port 3: 0=Tagged, 1=Filtered, 2=Untagged
e = property of port 4: 0=Tagged, 1=Filtered, 2=Untagged
SVT=
SVT?
SVT*
SVT#
SVT?
SVT=aaaabcde,aaa
abcde,aaaabcde…
(see Description of
Arguments)
Add entry to
VLAN table
SVA=
8 bytes
Command only.
Adds entry to VLAN table in the form aaaabcde, where:
aaaa = New VLAN ID. Value range is 1-4095, must not be duplicate of any PVID or VLAN ID existing in
VLAN table.
b = property of port 1. 0=Tagged, 1=Filtered, 2=Untagged
c = property of port 2. 0=Tagged, 1=Filtered, 2=Untagged
d = property of port 3. 0=Tagged, 1=Filtered, 2=Untagged
e = property of port 4. 0=Tagged, 1=Filtered, 2=Untagged
SVA=
SVA?
SVA*
SVA#
N/A
SVA=aaaabcde
(see Description of
Arguments)
Management
VLAN ID
SMV=
4 bytes
Command or Query.
Management Port’s VLAN ID in the form aaaa, where:
aaaa = the ID number in the range 0001-4095.
SMV=
SMV?
SMV*
SMV#
SMV?
SMV=aaaa
(see Description of
Arguments)
