Comtech EF Data CDM-625 - Page 532

CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–62
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Delete entry in
VLAN table
SVD=
4 bytes
Command only.
Deletes VLAN table entry in the form aaaa, where:
aaaa = the VLAN ID number in the range 0001-4095.
SVD=
SVD?
SVD*
SVD#
N/A
SVD=aaaa
(see Description of
Arguments)
Packet
Processor
Card Enable
PPE=
1 byte, value
0 or 1
Command or Query.
Packet Processor Card Enable, in the form PPE=x, where:
0 = Packet Processor Card is Disabled
1 = Packet Processor Card is Enabled
Note: Change of this configuration results in modem auto-reboot only when IP Packet Processor option card
is installed and enabled. Otherwise, when the IP Packet Processor option card is not installed, this selection
is stored but is otherwise non-functional.
PPE=
PPE?
PPE*
PPE#
PPE?
PPE=x
(see Description of
Arguments)
QoS Mode
QOS=
2 bytes
Command or Query.
Qo (Quality of Service) Mode, in the form QOS=ab where:
a = Layer 2 QoS;
0 = Off, Layer 2 QoS is disabled
1 = VLAN Priority only
2 = Port Priority only
3 = VLAN and Port Priority
b =Layer 3 QoS;
0 = Off, Layer 3 QoS is disabled
1 = Advanced QoS Max / Priority (requires Advanced QoS FAST Option)*
2 = Advanced QoS Min Max (requires Advanced QoS FAST Option)*
3 = Advanced QoS DiffServ (requires Advanced QoS FAST Option)*
*Note: Layer 3 QoS settings 1 through 3 apply to modem only with IP Packet Processor option card installed
and enabled.
QOS=
QOS?
QOS*
QOS#
QOS?
QOS=ab
(see Description of
Arguments)
Switch Ports
Configuration
SPC=
47 bytes
Command or Query.
Sets/Returns Ethernet switch ports’ priority and PVID in the form
1abccccdxxx;2abccccdxxx;3abccccdxxx;4abccccdxxx, where:
1, 2. 3. 4 = Port number.
a = Port priority;
Value is 1, 2, 3 or 4 (the higher the number, the higher the priority).
b = Port Native Mode;
0 = Native Mode Disabled, 1 = Native Mode Enabled.
cccc = Port VLAN ID in the range of 0000-4095;
Value 0000 is only valid when port Native Mode is disabled.
d = Pause flow control;
0 = Off, 1 = On
xxx = Eeserved.
SPC=
SPC?
SPC*
SPC#
SPC?
SPC=1abccccdxxx,2
abccccdxxx,3abcccc
dxxx,4abccccdxxx
(see Description of
Arguments)
