CDM-625 Advanced Satellite Modem Revision 13
Appendix D MN-CDM625
D–63
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction &
Qualifier)
Response to
Query
Edit entry in
VLAN table
SVE=
8 bytes
Command only.
Edit VLAN table entry in the form aaaabcde, where:
aaaa = existing VLAN ID. Value range is 1-4095.
b = property of port 1;
0=Tagged, 1=Filtered, 2=Untagged
c = property of port 2;
0=Tagged, 1=Filtered, 2=Untagged
d = property of port 3;
0=Tagged, 1=Filtered, 2=Untagged
e = property of port 4;
0=Tagged, 1=Filtered, 2=Untagged
SVE=
SVE?
SVE*
SVE#
N/A
SVE=aaaabcde
(see Description of
Arguments)
Packet
Processor
Working Mode
WMD=
1 byte, value
0 thru 3
Command or Query.
Packet Processor Working Mode in the form x, where:
0 = Managed Switch
1 = Router Point to Point*
2 = Router Multipoint Hub*
3 = Router Multipoint Remote*
*Note: Settings 1 through 3 apply to modem only with IP Packet Processor option card installed and enabled.
WMD=
WMD?
WMD*
WMD#
WMD?
WMD=x
(see Description of
Arguments)
Dedicated
Management
Port
DMP=
1 byte, value
0 thru 8
Command or Query.
Dedicated Ethernet Management port in Redundancy system in the form x, where:
0 = Disabled (Any Ethernet port can do management, default value)
1 = Port 1
2 = Port 2
3 = Port 3
4 = Port 4
5 = Port 1 – Local only*
6 = Port 2 – Local only*
7 = Port 3 – Local only*
8 = Port 4 – Local only*
Notes:
1. VLAN must be Disabled to be able to select a port as Dedicated Management Port.
2. * Only LAN devices can access M&C of modem. NO remote modem access.
DMP=
DMP?
DMP*
DMP#
DMP?
DMP=x
(see Description of
Arguments)
Ethernet 2048
Frame Size
EFS=
1 byte, value
0 or 1
Command or Query.
2048 byte Ethernet Frame Size Enable/Disable in the form x, where:
0 = 2048 Ethernet Frame Size is Disabled
1 = 2048 Ethernet Frame Size is Enabled (supported by modem with baseboard hardware Rev2 and
above)
EFS=
EFS?
EFS*
EFS#
EFS?
EFS=x
(see Description of
Arguments)
