BRAKE WEAR SENSOR-LEFT FRONT
CAV CIRCUIT FUNCTION
116BR GROUND
2 16BR/WT BRAKE WEAR SENSOR SIGNAL
BRAKE WEAR SENSOR-LEFT REAR
CAV CIRCUIT FUNCTION
116BR GROUND
2 16BR/WT BRAKE WEAR SENSOR SIGNAL
BRAKE WEAR SENSOR-RIGHT FRONT
CAV CIRCUIT FUNCTION
116BR GROUND
2 16BR/WT BRAKE WEAR SENSOR SIGNAL
BRAKE WEAR SENSOR-RIGHT REAR
CAV CIRCUIT FUNCTION
116BR GROUND
2 16BR/WT BRAKE WEAR SENSOR SIGNAL
C100 - (MAIN BODY SIDE)
CAV CIRCUIT
1 18BK/BL
2 18RD/DG
3 16WT/BL/RD
4-
516RD
616BK
7 16BK/BL
8 14BK/VT
9-
10 -
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTS VA
