(25) Un screw Torx socket bolts (4) (Fig. 46) and
remove oil pump (6). Scr ew two opposed bolts into
the oil pump housin g a nd pr ess the oil pump out of
the conver ter hou sing by applying light blows with a
plast ic ham mer.
(26) Remove and discard t he torqu e con verter hub
seal an d the oil pump outer o-ring seal fr om the oil
pump.
(27) Un screw Torx socket bolts (1) (Fig. 46) and
remove m ultiple-disc holding clu tch B1 (5) fr om con-
vert er housing. Screw two opposed bolts into t he
multiple-disc holding clutch B1 (5) and separa te from
the conver ter hou sing by applying light blows with a
plast ic ham mer.
(28) Deta ch intermediate pla te (3) (Fig. 46) from
conver ter hou sing (2).
Fig. 46 Remove Holding Clutch B1 and Oil Pump
1 - BOLTS - M6X32 4 - BOLTS - M8X35
2 - CONVERTER HOUSING 5 - HOLDING CLUTCH B1
3 - INTERMEDIATE PLATE 6 - OIL PUMP
21 - 50 AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION VA
