(3) In st all the Torx! socket bolts (3) (Fig. 144) a nd
torqu e to 8 N·m (71 in.lbs.).
(4) In st all a new oil filter (4) (Fig. 144).
(5) In st all oil pan (5) (Fig. 144) an d torque the oil
pa n bolts t o 8 N·m (71 in . lbs.).
(6) In st all the oil dra in plug (8) (Fig. 144) wit h a
new dr ain plug gasket (9). Torque the dra in plug to
20 N·m (177 in.lbs.).
(7) In st all th e guide bushing (2) (F ig. 144) into the
transmission hou sing an d inst all th e bolt (11) to hold
the guide bushing in place.
(8) Check O-rin g on plug conn ector (1) (F ig. 145),
and replace if necessa ry.
(9) In st all the plug connect or (1) into the guide
bushing (2). Turn bayon et lock of guide bush ing (2)
clockwise to connect plug connect or (1).
(10) Posit ion the hea t shield (2) (F ig. 146) ont o the
transmission hou sing and install t he screw (1) and
bolt (3) t o hold t he shield in place.
(11) Fill t he tr ansmission with the correct oil
(Refer to LUBRICATION & MAINTENANCE/FLUID
TYPE S - DE SCRIPTION) using the standard proce-
du re (Refer to 21 - TRANSMISSION/AUTOMATIC -
NAG1/F LUID AND F ILTER - STANDARD PROCE-
DURE - TRANSMISSION FILL).
Fig. 144 Install Electrohydraulic Unit
1 - HEAT SHIELD
2 - ELECTROHYDRAULIC UNIT
3 - BOLT
4 - OIL FILTER
5 - OIL PAN
6 - CLAMPING ELEMENT
7 - BOLT
8 - DRAIN PLUG
9 - DRAIN PLUG GASKET
10 - 13-PIN PLUG CONNECTOR
11 - BOLT
12 - GUIDE BUSHING
Fig. 145 Install Wiring Connector Plug
1 - PLUG CONNECTOR
2 - GUIDE BUSHING
Fig. 146 Install Heat Shield
1 - SCREW
2 - HEAT SHIELD
3 - BOLT
21 - 130 AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION VA
