(7) Loosen cen ter r oller bolt a nd adjust the fron t
and rear gaps.
(8) Check rear ridge pat tern alignment and
tighten bolt to 45 N·m (33 ft. lbs.).
Flush Adjustment
(1) Loosen upper roller arm scr ew. (Fig. 21)
(2) Loosen lower r oller a rm screws.
(3) Adjust front of door flu shness by alt erin g posi-
tion of t op a nd bott om roller arm s.
(4) Tighten upper an d lower r oller arm a djust ment
scr ews.
(5) In st all door striker a nd ha nd tight en the bolts.
(6) Adjust door striker in and out to adjust rear
door flushn ess.
(7) Tighten striker bolt s to 25 N·m (18 ft. lbs.).
(Fig. 18)
(8) Loosen stabilizer closing wedge screws. (Fig.
22)
(9) Close sliding door to adjust closing wedge.
(10) Open door and t ighten scr ews t o 10 N·m (89
in. lbs.).
Door Stop Bumper Adjust
(1) Loosen door st op bumper bolts.
(2) Open sliding door and h old tight in en d posi-
tion.
(3) Hold stop bumper tigh t again st c-pillar and
tighten bolts t o 10 N·m (89 in. lbs.).
STABI LI Z ER
REMOVAL
(1) Remove screws and remove stabilizers. (Fig.
23)
INSTALLATION
(1) In st all receiver a nd insta ll scr ews.
(2) Tighten screws to 10 N·m (89 in. lbs.).
Fig. 21 IN/OUT ADJUST
1 - IN/OUT ADJUSTMENT SCREW - UPPER ARM
2 - IN/OUT ADJUSTMENT SCREWS - LOWER ARM
Fig. 22 SLIDING DOOR STABILIZER
1 - SCREWS
2 - GUIDE WEDGES (2)
3 - SCREWS
4 - RECEIVERS (2)
Fig. 23 SLIDING DOOR STABILIZER
1 - SCREWS
2 - GUIDE WEDGES (2)
3 - SCREWS
4 - RECEIVERS (2)
VA DOORS - SLIDING 23 - 45
