(9) Relea se clips at fron t and rear of headliner and
remove.
Number 4 Section
(1) Disconn ect and isolate battery negative ca ble.
(2) Remove th e third and fou rth row sea ts. (Refer
to 23 - BODY/SE ATS/SE AT - REAR - RE MOVAL)
NOTE: If vehicle is not equipped with rear air con-
ditioning unit, skip to step 8.
(3) Remove the push pin fasteners and rem ove the
rear a ir front du ct cover.
(4) Disconn ect t he electr ical con nector at front of
cover.
(5) Remove the push pin fasteners and rem ove the
rear a ir middle duct cover.
(6) Disconn ect the electrical conn ector.
(7) Remove the three push-pin s an d th ree screws
and rem ove the rea r air cover.
(8) Remove the du ct work.
(9) Relea se clips at fron t and rear of headliner and
remove.
INSTALLATION
Cab Section
(1) Position th e h eadliner in veh icle and seat fu lly.
(2) In st all dome ligh t. (Refer to 8 - ELE CTRICAL/
LAMPS/LIGHTING - INTERIOR/CARGO LAMP
UNIT - INSTALLATION)
(3) In st all assist handle. (Refer t o 23 - BODY/IN-
TERIOR/ASSIST HANDLE - INSTALLATION)
(4) In st all b-pillar trim. (Refer t o 23 - BODY/IN-
TERIOR/B-P ILLAR TRIM - INSTALLATION)
(5) In st all th e sun visors. (Refer to 23 - BODY/IN-
TERIOR/SUN VISOR - INSTALLATION)
(6) In st all the a-pillar trim. (Refer to 23 - BODY/
INTERIOR/A-PILLAR TRIM - INSTALLATION)
(7) Connect batt ery n egat ive cable.
Number 2 Section
(1) Position th e h eadliner in veh icle and seat fu lly.
NOTE: If vehicle is not equipped with rear air con-
ditioning unit, skip to step 8.
(2) In st all rea r air un it duct work.
(3) In st all th e rear air unit rea r cover a nd install
the t hree screws and pu sh -pins.
(4) Connect the electrical connector a nd insta ll th e
middle duct work cover.
(5) In st all the push pin fasten ers.
(6) Connect the electrical connector a nd insta ll th e
front duct wor k cover.
(7) In st all the push pin fasten ers.
(8) In st all the second and third row seats. (Refer
to 23 - BODY/SE ATS/SE AT - INSTALLATION)
(9) Connect batt ery n egat ive cable.
Number 3 Section
(1) Position th e h eadliner in veh icle and seat fu lly.
NOTE: If vehicle is not equipped with rear air con-
ditioning unit, skip to step 8.
(2) In st all rea r air un it duct work.
(3) In st all th e rear air unit rea r cover a nd install
the t hree screws and pu sh -pins.
(4) Connect the electrical connector a nd insta ll th e
middle duct work cover.
(5) In st all the push pin fasten ers.
(6) Connect the electrical connector a nd insta ll th e
front duct wor k cover.
(7) In st all the push pin fasten ers.
(8) In st all the th ird and fourt h r ow seats. (Refer t o
23 - BODY/SEATS/SEAT - INSTALLATION)
(9) Connect batt ery n egat ive cable.
Number 4 Section
(1) Position th e h eadliner in veh icle and seat fu lly.
NOTE: If vehicle is not equipped with rear air con-
ditioning unit, skip to step 8.
(2) In st all rea r air un it duct work.
(3) In st all th e rear air unit rea r cover a nd install
the t hree screws and pu sh -pins.
(4) Connect the electrical connector a nd insta ll th e
middle duct work cover.
(5) In st all the push pin fasten ers.
(6) Connect the electrical connector a nd insta ll th e
front duct wor k cover.
(7) In st all the push pin fasten ers.
(8) In st all the th ird and fourt h r ow seats. (Refer t o
23 - BODY/SEATS/SEAT - INSTALLATION)
(9) Connect batt ery n egat ive cable.
QU ART ER T RI M PAN EL
REMOVAL
Passenger Van
(1) Remove seat s as necessar y. (Refer to 23 -
BODY/SEATS/SEAT - REMOVAL)
(2) Remove d-pilla r trim if necessary. (Refer to 23 -
BODY/INTERIOR/D-PILLAR TRIM - RE MOVAL)
(3) Usin g a trim stick C-4755 or equivalent, sepa -
rate the pu sh -pin fasten ers an d r emove trim panels.
Cargo Van
(1) Remove bolts and remove t ie down rings, if
equ ipped .
(2) Remove rivets and remove paneling
23 - 74 INTERIOR VA
