INSTALLATION
(1) In st all scuff pad a nd install the scr ews.
(2) In st all the trim plugs.
(3) In st all the seat bracket , if n ecessary.
SU N V I SOR
REMOVAL
(1) Remove th e support screws and remove the
visor. (Fig. 10)
INSTALLATION
(1) Position visor and support on h eader.
(2) In st all the screws.
Fig. 9 SLIDING DOOR SCUFF PAD
1 - TRIM PLUGS
2 - SCREWS (5)
3 - SCUFF PAD
Fig. 10 SUN VISOR
1 - SUN VISOR
2 - SCREWS
3 - SUPPORTS (2)
23 - 76 INTERIOR VA
