(10) Remove the th ree foam insulator s from t he
right in ner qua rter panel (F ig. 29).
(11) Disengage th e rea r A/C dischar ge line from
the two retaining clips locat ed on the inner quar ter
pa nel and pu ll the discharge line down from the top
of the vehicle into the ca rgo compart ment.
(12) Disen gage the rear A/C discharge line fr om
the t wo ret aining clips located undern eath of the
vehicle.
(13) Disconn ect t he rear A/C disch arge lin e fr om
the under body discharge line and r emove an d discard
the O-rin g seal.
(14) Remove the foam rubber sea l fr om t he open-
ing in the floor of the car go compart ment and pull
the rear A/C discha rge lin e out from u ndernea th the
vehicle.
(15) Install plugs in to, or ta pe over th e open ed
rear discha rge and underbody line fit tings an d con-
denser t ube.
Fig. 28 Rear A/C Wire Harness
1 - REAR A/C EVAPORATOR HOUSING
2 - REAR A/C DISCHARGE LINE
3 - RETAINING STRAP
4 - REAR A/C WIRE HARNESS
VA PLUMBING 24 - 89
