EMISSIONS CONTROL
TAB LE O F CO NTE NTS
page page
EVAPORATIVE EMISSIONS ..................1 EXHAUST GAS RECIRCULATION .............4
EVAPORAT I V E EM I SSI ON S
TABLE OF CONTENTS
page page
CRANKCASE VENTILATION HEATER
REMOVAL .............................1
INSTALLATION ..........................1
CRANKCASE VENTILATION BREATHER
DESCRIPTION ..........................2
REMOVAL .............................2
INSTALLATION ..........................3
CRAN K CASE V EN T I LAT I ON
HEATER
REMOVAL
(1) Disconn ect the n egat ive battery cable.
(2) Remove the turboch arger hea t shield.
(3) Disconn ect the CCV heat er wirin g ha rness con-
nector.
(4) Usin g a sligh t twisting mot ion, separ ate the
CCV brea ther t ube from the heater.
(5) Sepa rat e the CCV heater from the tu rbo-
charger air inlet duct.
INSTALLATION
(1) Clean all mat ing surfaces.
(2) In sert the CCV heater into the t urboch arger
inlet hose aligning the arrow on th e hea ter with the
tab on the h ose (Fig. 1).
(3) Connect and proper ly seat t he CCV brea ther
hose on the CCV heater (Fig. 1).
Fig. 1 CCV HEATER
1 - BREATHER HOSE
2 - HARNESS CONNECTOR
3 - TURBOCHANGER INLET HOSE
4 - HEATER ALIGNMENT AREA
5 - CCV HEATER
VA EMISSIONS CONTROL 25 - 1
