(4) Pull apart pr opeller sh aft.
(5) Remove snap-r ing (Fig. 12).
NOTE: If center bearing is equipped with a round
flange remove bolt from the middle of the flange.
(6) Pull off cent er bearing with a Bearing Splitt er
1130 a nd Bridge 938, with a plug on the end of th e
sh aft (Fig. 13).
NOTE: The bearing splitter must be positioned
behind the thrust washer of the bearing.
INSTALLATION
(1) Press cent er bearing on propeller shaft with
pr otective caps and wa sh er with In st aller 9275 (Fig.
14).
Fig. 11 BOOT
1 - BOOT
2 - CLAMP
3 - SHAFT
Fig. 12 CENTER BEARING
1 - SNAP-RING
2 - CENTER BEARING
3 - WASHER
4 - SHAFT
5 - PROTECTIVE CAP
Fig. 13 CENTER BEARING REMOVAL
1 - BRIDGE
2 - PLUG
3 - BEARING SPLITTER
4 - CENTER BEARING
Fig. 14 CENTER BEARING INSTALLATION
1 - INSTALLER
2 - CENTER BEARING
3-10 PROPELLERSHAFT VA
