SPECI AL T OOLS
PARK BRAKE
SPECI AL T OOL CROSS REFEREN CE CH ART
MB
TOOL #
MILLER
TOOL #
DESCRIPTION
116 589
01 62 00
9280 RETURN SPRING PULL-
ING HOOK
112 589
09 61 00
9281 RETAINING SPRING
TOOL
901 589
00 63 00
9289 RETAINING CLIP RE-
LEASE TOOL
CABLE T EN SI ON ER
REMOVAL
NOTE: Observe the installation position of the
brake control cable lock, for a reference on instal-
lation.
(1) Open the brake con trol cable lock (Fig. 28).
(2) Press out th e safety bolt an d r emove t he bra ke
control cable lock (Fig. 28).
INSTALLATION
(1) Push the brake control ca ble lock onto the
brake ca ble (Fig. 28).
(2) In sert the safet y bolt a nd sna p shut the bra ke
control cable lock. Ob s e rv e t h e i n s t a ll a ti o n p o s i -
tion of the brake control cable lock (Fig. 28).
CABLES
REM OVAL
REMOVAL - FRONT
(1) Raise and support the vehicle.
(2) Disconn ect th e front park brake cable from the
pulley un it.
(3) Remove the front par k bra ke cable from the
hand br ake lever (Fig. 29).
RETAINING CLIP RELEASE TOOL - 9289
RETAINING SPRING TOOL - 9281
RETURN SPRING PULLING HOOK - 9280
Fig. 28 CONTROL CABLE LOCK
1 - BRAKE CABLE CONTROL LOCK OPEN
2 - BRAKE CABLE CONTROL LOCK CLOSED
3 - BRAKE CONTROL CABLE LOCK
4 - SAFETY BOLT
5 - INSTALLATION POSITION OF BRAKE CONTROL CABLE
LOCK
5-24 BRAKES-BASE VA
