CH ARGI N G SY ST EM
TABLE OF CONTENTS
page page
CHARGING SYSTEM
SPECIFICATIONS
TORQUE – 2.7L DIESEL . . . . . . . . . . . . . . . . 17
SPECIAL TOOLS . . . . . . . . . . . . . . . . . . . . . . . 18
GENERATOR
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . 18
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 19
GENERATOR DECOUPLER PULLEY
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . 19
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
DIAGNOSIS AND TESTING - GENERATOR
DECOUPLER . . . . . . . . . . . . . . . . . . . . . . . . . 20
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 22
VOLTAGE REGULATOR
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . 24
REMOVAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 26
CH ARGI N G SY ST EM
SPECI FI CAT I ON S
TORQUE – 2.7L DIESEL
DESCRIPTION N-m Ft. Lbs. In. Lbs.
B+ Terminal Nut (larger of
2 nuts)
18 - 159
D+ Terminal Nut (smaller
of 2 nuts)
5 - 44
Rear Generator Support
Bracket Bolts (to engine)
28 - 250
Generator Decoupler 110 81 -
Generator/Turbocharger
Brace Bolt at Turbocharg-
er End
30 22 -
Generator/Turbocharger
Brace Bolt at Engine End
20 15 -
VA CHARGING SYSTEM 8F - 17
