S4-10-D Pediatrics,
Neonatal,
Abdomen
B, CHI, CF, PDI, M, MCF, PW, CW, TVI,
TVD, Virtual Convex, LOGIQView, ATO/
ASO, SRI-HD, Advanced 3D
5394804 Sector
1 1
6Tc-RS Cardiac
(Transesophageal)
B, CHI, CF, PDI, M, MCF, PW, CW, TVI,
TVD, Virtual Convex, ATO/ASO, SRI-HD
Note: Need DLP2RS adapter to connect.
Note: 6Tc-RS probe requires special
handling. Refer to the TEE Probe User
Manual enclosed with 6Tc-RS probe.
KN100104 TEE
1 1
P2D Cardiac, Vascular CW, ASO
TE100024
Pencil
Probe
11
P6D Cardiac, Vascular CW, ASO
TQ100002
Pencil
Probe
11
Table 9-10 Probe Description
Part
Name Illustration Application Feature
Part
Number
Probe
Type Qty FRU
