iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
111
Table 4.4.4.1-1 Common Attributes
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
DISA Delay
Timer
Once answered, the system attaches a DTMF receiver to the
DISA call to receive caller-dialed digits. This timer introduces a
delay before attaching the DTMF receiver to the CO line.
(Intended for Russia only)
0-9
seconds
0
DISA Answer
Timer
When a call is received on a CO line with DISA service, the
system will answer the call when the DISA Answer Timer expires.
(Intended for Russia only)
0-9
seconds
0
Tone Attributes
CO Line MOH
A held call can be connected to one (1) of ten (10) possible audio
sources while on Hold as Music-on-Hold (MOH).
Refer to Sys Hold, Internal Music, External Music, VSF MOH,
SLT MOH1~5, VSF MOH2~30
Refer to
description
Refer to
Sys Hold
CO Dial Tone
ISDN Lines may provide a digital signal rather than actual tones.
In this case, the iPECS can provide the tones. If the ISDN
provides the tone, the Tone is “ON” for an iPECS system-
generated tone. The tone is set to “OFF.”
OFF
ON
ON
CO Ring Back
Tone
OFF
ON
OFF
CO Error Tone
OFF
ON
OFF
CO Busy Tone
OFF
ON
OFF
CO Line Dial
Tone Source
One of eleven sources can be defined as a dial tone for use by
the CO line.
Dial Tone, Internal Music, External Music, VSF MOH,
SLT MOH1~5, VSF MOH2~30
Refer to
description
Dial Tone
CO Ring Back
Tone Source
One of eleven sources can be defined as a ring-back tone for use
by the CO line.
Ring Back Tone, Internal Music, External Music, VSF MOH,
SLT MOH1~5, VSF MOH2~30
Refer to
description
Ring Back
Tone
COL Ring Tone
One of sixteen Ring Tones can be configured for use by this CO
Line.
00-16
0: NA
0
