iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
251
Table 4.4.8.1-1 SIP Common Attributes
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
SIP Pound Use
SIP employs Enblock dialing, where the user dials all digits before
they are sent to the carrier for processing. When the user
completes dialing of a SIP call, ‘#’ is used to indicate the end of
dialing. If users must be able to dial ‘#,’ SIP Pound Use can be
disabled, and the system will automatically send digits at the
expiration of the inter-digit time.
OFF
ON
OFF
BLF SYNC
NOTIFY Timer
When the system reboots, the button LEDs of SIP phones may
indicate erroneous status. To displays proper status LEDs, the
system sends a Notify message to synchronize the LED states at
the expiration of this timer.
10-360
10
SRTP
PATH(SIPEXT)
The SRTP path can be established through a VoIP channel
(Packet Relay) or directly between the end-points for SIP
extensions connected to the same LAN as the system.
VOIM
RELAY or
DIRECT
VOIM
RELAY
DNS SRV Usage
The system can be configured to query the DNS for the SRV
resource record, which defines domains for various services.
OFF
ON
OFF
Out OF Rsc
Response
When the system has no resources available for the SIP Request,
the system will respond with this code.
503/
486
503
Error Code For
Trunk Rerouting
The call will be rerouted if the iPECS system receives this Error
Code in response to a request—the semi-colon (;) is used to
separate multiple SIP message codes.
Intercom Busy
Service
When the SIP extension hears a busy tone, the Call Back feature
can be activated by pressing the # key.
 System Rule: Follow PGM160- Intercom Busy Service
 CallBack: Call Back feature
Refer to
description
System
Rule
Incoming Trunk
Choice
Incoming SIP trunk will be seized based on this admin setting
 System Rule: Follow PGM160 - CO Line Choice.
 Round: round-robin rule.
 Last: last available trunk
 First: first available trunk
Refer to
description
System
Rule
SIP QOS Option
SIP QOS Method
Selection
For SIP messages, the system can employ Diff-Serv or TOS to
implement QoS.
DSCP/
TOS
TOS
SIP Signal DSCP
value
When Diff-Serv is selected as the QoS method, the DSCP value
for SIP signaling messages is defined.
0~63
0
SIP Signal TOS
value
When TOS is selected as the QoS method, the TOS value for SIP
signaling messages is defined.
0~7
5
RTP DSCP value
When DSCP is selected as the QoS method, the DSCP value for
RTP packets is defined.
0~63
0
RTP TOS value
When TOS is selected as the QoS method, the TOS value for
RTP packets is defined.
0~7
5
SIP T-NET Option
CM Prefix
Korea Telecom only, when employing an iPECS system as the
CM, iPECS system will require a Prefix to set up a SIP trunk call.
Max. 6
Digits
