iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
252
Table 4.4.8.1-1 SIP Common Attributes
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
CM Prefix
Method
Korea Telecom only enables the Prefix method for processing a
call with a SIP trunk through the iPECS system.
Normal,
With prefix
Normal
SIP Trunk Register Option
Register Retry
Timer
When registration fails, the iPECS system attempts to register
periodically at intervals of this timer.
20~3600
60
Option Check
number
Korea Telecom only, a SIP Options message is used for
redundancy. If the system does not respond to the Options
message after the number of attempts, the redundant server
becomes active
1~20
1
Option Check
Interval
Korea Telecom only, a SIP Options message is used for
redundancy. The Option message is sent at intervals of this timer.
20~3600
20
SIP Alarm Server Option
Alarm Server
Usage
If this value is changed, all WTIB will restart.
OFF/ON
OFF
Alarm Server
Address
Enter the alarm server address up to 32 characters.
Max. 32
characters
Alarm Server
UDP Port
Default UDP port for Alarm server.
Port
5060
Alarm Server
Check Usage
If IPECS doesn’t receive a reply for this option 3 consecutive
times, will not send Message and Information to the Alarm Server.
PGM 210 check message send timer.
OFF/
ON
OFF
Terminal State
Announcement
Information (Terminal state) is sent to the Alarm server if this
value is ON, not sent to the Alarm server if this value is OFF.
OFF/
ON
OFF
600BE Channels
for Alarm
The number of 600BE channels reserve for Alarm SMS.
0~1
0
SIP MULTIHOME Option
SIP Multi-home
Usage
Usage for Secondary IP and Secondary UDP port in SIP
signaling.
 OFF: Secondary IP and secondary UDP port are not used.
 EXT UDP Port: PGM210-SIP Multi-home Ext UDP Port is
used as a secondary UDP port.
 2nd IP: PGM210-SIP Multi-home 2nd IP is used as
secondary IP. Multi-home 2nd IP UDP Port, Multi-home 2nd
IP TCP Portland Multi-home 2nd IP TLS Port are used with
secondary IP.
 EXT UDP Port+2nd IP: Multi-home Ext UDP Port and Multi-
home 2nd IP is used.
Refer to
description
OFF
SIP Multi-home
Ext UDP Port
Ext UDP Port is used for secondary UDP port. This port is just
used for SIP Extension.
Port
5070
SIP Multi-home
2nd IP
Multi-home 2nd IP is used for secondary IP for SIP signaling. It is
different with System IP
Max. 32
characters
0.0.0.0
Delete Second
Route
If this value is Yes, the routing table for PGM 210-SIP Multi-home
2nd IP is deleted.
The default route is used for 2nd IP.
No,
Yes
No
